Nova Onder Trailer 3 AXLE TIPPING SEMI TRAILER poluprikolica kipera

ÖNDER TRAILER – TIPPING SEMI TRAILER (POOL TYPE)

Power, Durability and Efficiency in One!

Önder Trailer Pool Type Tipping Semi-Trailers are designed to deliver maximum performance in demanding sectors such as construction, mining, agriculture, and heavy transport.
With high loading capacity, reinforced body structure, and advanced technological features, they ensure efficiency, safety, and long-lasting operation.

All specifications can be customized according to your specific needs.
We can modify materials, dimensions, and design options upon request.
Our engineering team and design workshop are always at your service!

STANDARD TECHNICAL SPECIFICATIONS

Overall Dimensions: 2550 mm (width) x 9875 mm (length) x 3420 mm (height)
King Pin Height: 1400 mm
Axle Distance: 1310 mm
Unladen Weight: 7,500 kg
Gross Vehicle Weight: 40 tons

SUSPENSION SYSTEM

Mechanical Suspension: High durability and low maintenance cost on rough terrains

Air Suspension: Smooth driving and enhanced comfort

TIRES / RIMS

Dual tire system 385/65 R22.5 (6+1 set)

Ensures maximum balance and safety under heavy loads

BRAKE SYSTEM

Dual circuit system in compliance with ECE R13 regulations

2S/2M electronic ABS + WABCO RSS

Emergency stop and slope valve

TIPPING SYSTEM

Front telescopic cylinder

Minimum tipping angle 45°

High strength steel cylinder

ELECTRICAL SYSTEM

7x24V lighting system in compliance with ECE R48

AXLE SET

12 ton capacity axles

Optional configurations: 9–12–14 tons

HYDRAULIC EQUIPMENT

Pump: 35–90 lt/min twin gear pump

Hoses: R2 steel braided hoses, pressure resistant up to 250 bar

Oil Tank: Filtered, sealed, and custom-designed

LANDING LEGS

24 ton capacity, two-stage telescopic legs

SIDE GUARDS / MUDGUARDS

In compliance with ECE R73 (fixed or foldable type)

Full FRP mudguards over the wheels

PAINTING PROCESS

SA 2.5 sandblasting and chemical cleaning

Double layer epoxy primer and baked acrylic paint

Optional zinc-rich or metallization application upon request

BODY MATERIAL

HARDOX 450 Brinell or 500 TUF wear-resistant steel

Volume: 18–32 m³ (standard model: 30 m³)

ADDITIONAL FEATURES

King Pin: ECE R55 compliant, 2” bolted detachable flange type

Rear Bumper: ECE R58 compliant flexible type (optional pneumatic folding system)

Rear Pallet: 450 HB wear plate design for asphalt transport

Floor / Side Walls: 5/4 mm imported wear plate (450–500 TUF hardness)

Front Panel / Rear Door: HARDOX 450 / 500 TUF wear plates

Tarp System: Hydraulic, sliding, or automatic options available

Chassis: S700MC imported or S355JR domestic reinforced heavy-duty chassis

FIELDS OF APPLICATION

Our pool type tipping semi-trailers are versatile and reliable partners for various industries:

Construction: Excavation, stone, sand, asphalt, concrete transport

Mining: Ore, coal, quarry materials

Agriculture: Bulk grain, sugar beet, potatoes, etc.

Recycling: Scrap, industrial waste, plastic, paper

ÖNDER TRAILER ADVANTAGES

✅ Guaranteed delivery deadlines – No delays.
✅ 48-hour roadside assistance in Turkey and EU countries.
✅ 10-year spare parts availability guarantee.
